Quantum DXi6900 User Manual

Chapter 9: Configuration
OST Configuration
Quantum DXi6900 User’s Guide 267
1. Select the mapped IP address and click Edit.
The EditTargetDataIPMapping window displays (see Figure 165 below).
Figure165:Edit Target Data IP Mapping
2. In the TargetReplicationIP box, enter the replication IP address to map the data IP address to.
Note:If you are editing a mapped IP address, you cannot change the target data IP address.
3. Click Apply.
Deleting a Mapped IP Address
Delete a mapped IP address if traffic sent to the target data IP address no longer needs to be routed to a
replication IP address
To delete a mapped IP address, select the IP address and click Delete.
Note:You can select multiple mapped IP addresses to delete at once.
DXi Accent
Use theAccent page to enable or disable DXi Accent. Quantum’s DXi Accent software accelerates
backups and reduces network bandwidth requirements by distributing deduplication between the backup
server and the DXi. OST data sent from the media server to the DXi can be encrypted using AES
(Advanced Encryption Standard) encryption methods.
To access the Accent page, on the OST page, click the Accent tab (see Figure 166 below).
Figure166:Accent Page
