Chapter 11: System Specifications
DXi6900 Physical Characteristics
Quantum DXi6900 User’s Guide 386
DXi6900 Cable Drops
DXi6900CableDrops
EthernetCableDrops
DXi6900G1(3x1GbEportsand2x10GbEports) - 1 to 3 1GbE Ethernet
connections and 1 to 2 10GbE Ethernet connections (optical or Twinax, see
below) for NAS or OST connectivity, replication, and remote management.
DXi6900G1(7x1GbEportsand2x10GbEports) - 1 to 7 1GbE Ethernet
connections and 1 to 2 10GbE Ethernet connections (optical or Twinax, see
below) for NAS or OST connectivity, replication, and remote management.
DXi6900G1(3x1GbEportsand4x10GbEports) - 1 to 3 1GbE Ethernet
connections and 1 to 4 10GbE Ethernet connections (optical or Twinax, see
below) for NAS or OST connectivity, replication, and remote management.
DXi6900G2/DXi6900-S(3x1GbEports) - 1 to 3 1GbE Ethernet connections
for for NAS or OST connectivity, replication, and remote management.
DXi6900G2/DXi6900-S(6x10GbEports) - 1 to 6 10GbE Ethernet
connections (optical,Twinax, CAT6, see below) for NAS or OST connectivity,
replication, and remote management.
Note:For Cisco 5000 Series Data Center Class switches, Quantum
recommends using the approved 5 meter Twinax cable type that is shipped
with the DXi6900 system. Otherwise, Quantum recommends using optical
(SFP+) connectivity.
Note:The 10 GbE Copper (Twinax) cable options that Quantum provides do
not support all switches. Please note the supported switches during the
purchase-configuration process, and if the Twinax cables supplied by
Quantum are not compatible with your switch, then you will need to provide
your own compatible Twinax cables from your switch vendor. Be sure to
have these available before the system installation takes place.
