Chapter 1: System Description
Drive Storage
Quantum DXi6900 User’s Guide 27
Figure8:DXi6900 Drive Carrier
Figure9:DXi6900 Hard Drive Carriers - Array and Expansion Modules
SDDs
The DXi6900-S Node supports thirteen high capacity (800 GB) solid state drives (SDDs) (see Figure 10 on
the next page). The Node hard drives are used for the operating system, system software, and indexes
needed for data deduplication, replication, and space reclamation.
All solid state disk drives are mounted and pre-assembled in drive carriers (see Figure 10 on the next page).
All drives are hot swappable.
