Quantum DXi6900 User Manual

Chapter 2: Basic Operations
DXi6900 Node
Quantum DXi6900 User’s Guide 42
l DXi6900 Node 1 GbE Ethernet on page 51
l DXi6900 Node 10 GbE Ethernet Port Indicators on page 52
l DXi6900 Node 10 GBase-T Ethernet Port Indicators on page 52
l DXi6900 Node Power Supply Indicators on page 53
DXi6900 Node Front Panel Features and Indicators
Figure 17 below and Figure 18 on the next page shows the controls, indicators, and connectors located
behind the optional rack bezel on the front panel of the Node. Table 1 on the next page describes each item.
Figure17:DXi6900 Node Front View
1
2
3
4 5 6
7
8
9 10
