Chapter 9: Configuration
Notifications
Quantum DXi6900 User’s Guide 295
To manually send a status data or configuration data report:
1. Under EmailType, select the type of report to send (Statusdata or Configurationdata).
2. In the SendTo box, enter the e-mail address of the recipient.
3. Click Send.
ViewingConfigurationData
To view a configuration data report:
1. Under EmailType, select Configurationdata.
2. Click View.
The SystemConfigurationReport window displays.
3. (Optional) Click Save to save a local copy of the report in TXT format.
SNMP
The SNMP page allows you to configure the DXi6900 to send status messages using SNMP (Simple
Network Management Protocol). The DXi6900 supports SNMP v1 and v2c.
SNMP works by sending messages, called protocol data units (PDUs), to different parts of a network, or
communities. SNMP compliant devices, called agents, store data about themselves in Management
Information Bases (MIBs) and return this data to the SNMP requesters.
You can configure the DXi6900 to act as an agent and send traps to a specified destination. You can also
add SNMP community information.
To access a copy of the SNMP MIB file, see SNMP MIB File).
To access the SNMP page, on the Notifications page, click the SNMP tab.
The SNMP page contains the following tabs:
l Destinations below
l Community on page 299
l Test on page 304
Destinations
The Destinations page allows you to manage the destinations the DXi6900 sends SNMP traps to. You can
add, edit, and delete SNMP destinations, and you can specify the types of traps to send.
To access the Destinations page, on the SNMP page, click the Destinations tab (see Figure 183 on the
next page).
