Chapter 11: System Specifications
DXi6900 Physical Characteristics
Quantum DXi6900 User’s Guide 391
Voltage Node 100–240 VAC
Expansion Module (RBOD) 100–240 VAC
Frequency Node 50–60Hz
Array Module (RBOD) 50–60Hz
Expansion Module (EBOD) 50–60Hz
AverageACCurrent Node 613 Watts, 6.1A @100 VAC 2000 BTU/hr
613 Watts, 2.6A @240 VAC 2000 BTU/hr
Array Module (RBOD) 334 Watts, 3.3A @100 VAC 1140 BTU/hr
334 Watts, 1.4A @240 VAC 1140 BTU/hr
Expansion Module (EBOD) 228 Watts, 2.3A @100 VAC 780 BTU/hr
228 Watts, 1.0A @240 VAC 780 BTU/hr
InrushPeakACCurrent Maximum Configuration 95A @ 100 VAC 40A @ 240 VAC
Caution:To safeguard backups and to avoid potential data loss in the event of a power outage,
Quantum recommends that you connect the DXi6900 to an uninterruptable power supply (UPS) with a
minimum UPS capacity rating that meets the power requirements stated above.
DXi6900-S Power Requirements
DXi6900-SPowerRequirements
