Chapter 2: Basic Operations
DXi6900 Node
Quantum DXi6900 User’s Guide 50
PCISlot4 PCISlot5 PCISlot7
2 x 16 Gb Fibre Channel 2 x 16 Gb Fibre Channel
2 x 16 Gb Fibre Channel 2 x 16 Gb Fibre Channel 2 x 16 Gb Fibre Channel
2 x 10 Gb Ethernet *
2 x 10 Gb Ethernet * 2 x 10 Gb Ethernet *
2 x 10 Gb Ethernet * 2 x 10 Gb Ethernet * 2 x 10 Gb Ethernet *
2 x 10 Gb Ethernet * 2 x 16 Gb Fibre Channel
2 x 10 Gb Ethernet * 2 x 16 Gb Fibre Channel 2 x 16 Gb Fibre Channel
2 x 10 Gb Ethernet * 2 x 16 Gb Fibre Channel 2 x 10 Gb Ethernet *
* 2 x 10 Gb Ethernet = 2 x 10 GbE (SFP+) or 2 x 10 GBase-T Ethernet ports
Node Drive Carrier Indicators
Each DXi6900 hard drive carrier in the Node module has two LED indicators (see Figure 21 on the next
page):
LEDIndicator Activity
Driveactivityindicator(green) l Flashing - Indicates hard disk drive activity.
Drivestatusindicator(greenandamber) l Off - Drive ready for insertion or removal
Note:The drive status indicator remains off until
all drives are initialized after system power is
applied. Drives are not ready for insertion or
removal during this time.
l Blinksgreentwotimespersecond - Identify
drive/preparing for removal
l Blinksgreen,amber,andoff- Drive predicted
failure
l Blinksamberfourtimespersecond - Drive failed
l Blinksgreenslowly - Drive rebuilding
l Steadygreen - Drive online
l Blinksgreenthreeseconds,amberthree
seconds,andoffsixseconds - Rebuild aborted
