21. PERIPHERAL DEVICES
Menu PERIPHERAL DEVICES is located in menu group Parameters. It is accessed
by pressing Setup key or < Setup > quick access key and entering submenu
< Peripheral devices>. Inside the menu, there is a list of connectable
peripheral devices, which can cooperate with a moisture analyzer.
21.1. Computer
Active connection between a moisture analyzer and a computer is signaled by
visible pictogram displayed in the upper bar of the main window. Submenu <
Computer> enables configuring connection settings.
Procedure:
− press key and “ Peripheral devices / Computer” key
− set moisture analyzer’s parameters related to cooperation with a
computer
− computer port
o available options: none, COM 1, COM 2, Tcp
− address
o give address of a moisture analyzer which is connected to a
computer
− continuous transmission
o available options: NO, YES (printout format depends on set
printout template in a moisture analyzer – see next parameter).
− weighing printout template
o it is possible to design an individual printout to a computer using a
dedicated window with printout template. Principles on creating
printouts are described in point 24.11 of this user manual.
− E2R System
o E2R System is a modular system performing complex operations of
supervision and control over all weighing processes carried out on
a balance.
Caution:
Enabling parameter < E2R System> can only be carried out by moisture
analyzer’s manufacturer or authorized personnel.
If cooperation with E2R is enabled, then all changes on products, clients, users,
drying modes, etc. are possible only from the level of E2R computer software.
Access to carrying out changes in this data from moisture analyzer’s software level is
locked.
