21.3.3 Test
< Test> function enables correct operation of barcode scanner connected to
balance.
Procedure:
5. Open < Barcode scanner> submenu.
6. Press < Test> parameter; <Test> window opens with ASCII and HEX fields
in it.
7. Scanned barcode is entered into ASCII or HEX field; result of test is displayed in
the bottom part of the window.
When:
• <Prefix> and <Suffix> are identical for both – balance settings and scanned
barcode – the test is <Positive>.
• <Prefix> and <Suffix> differ for both – balance settings and scanned barcode –
the test is <Negative>.
21.4. Transponder card scanner
Selecting (logging) a user on each switching on the moisture analyzer can be
carried out by means of:
• Inserting user’s password using on-screen keyboard,
• With a transponder card scanner, by approximating a registered card to the
scanner.
Caution:
For correct moisture analyzer’s cooperation with a transponder card scanner set
appropriate baud rate value in submenu < Communication> (default 9600b/s).
Transponder card scanner port.
The moisture analyzer enables communicating with a transponder card
scanner using the following ports:
• RS 232 (COM1),
• RS 232 (COM2).
Assigning number of a card to a user:
In order to log in an operator using a transponder card scanner, first assign a
number of an already registered card to a selected user in the database of
operators.
Procedure:
• Connect a transponder card scanner to a moisture analyzer’s port (RS 232
COM1 or RS 232 COM2), select communication port in moisture analyzer
settings for the transponder card scanner
• In submenu < Communication> set baud rate for compatible with the
one of the transponder card scanner (default 9600b/s).
