16.12Targetoptions

TheTargetoptionsmenufortheChartapplicationandRadarapplicationareshownbelow.

ParameterDescriptionOptions

VectorLength

Thelengthofthevectorlinesdisplayed

dependsonthedistancethatanAIStarget

travelsinthetimeperiodthatyouspecifyfor

thissetting.

•0.5min

•1min

•3min

•6min

•12min

•30min

•60min

TargetHistoryTargets’previouspositionwillbeplottedasa

targeticonwithlightershadingthantheactual

targetforthetimespecied.

•Off(default)

•0.5min

•1min

•3min

•6min

AISfunction193
