4.7Networkconnections
YoucanconnectanumberofdigitaldevicestoyourmultifunctiondisplayusingtheNetworkconnector(s)
attherearoftheunit.
Atypicalnetworkofdigitaldevicesmayinclude:
•Upto6Raymarinemultifunctiondisplays.
•SeaTalk
hs
andRayNetdigitaldevicessuchasasonarmoduleandradarscanner.
•EthernetdevicessuchasIPcameras.
Yourmultifunctiondisplayincludes3networkconnectorswhichalsoprovidePoweroverEthernet(PoE).
NetworksrequiringadditionalnetworkconnectionswillrequireaRaymarinenetworkswitch.
TypicalSeaTalk
hs
network
SeaTalk
hs
/ RayNet
SeaTalk
hs
/ RayNetRayNet
RayNet
SeaTalk
hs
/ RayNet
SeaTalk
hs
/ RayNet
1 2 1 3 4 5
6
D12893-1
1.gSSeriesmultifunctiondisplay.
2.Remotekeypad(PoE).
3.Thermalcamera(PoE).
4.Sonarmodule.
5.Networkswitch.
6.Radarscanner.
IntheexampleaboveboththeRemotecontrolandthermalcameraaresuppliedPoweroverEthernet
(PoE)bythegSdisplays.
Note:TheRayNetcablesuppliedwiththedisplayincludesasuppressionferrite.2additionalsuppression
ferritesaresuppliedwiththedisplay,thesemustbeusedonanyadditionalnetworkconnections.
Networkcableconnectortypes
Thereare2typesofnetworkcableconnector—
SeaTalk
hs
andRayNet.
SeaTalk
hs
connector—usedfor
connectingSeaTalk
hs
devicesto
aRaymarinenetworkswitchvia
SeaTalk
hs
cables.
RayNetconnector—usedfor
connectingRaymarinenetwork
switchesandSeaTalk
hs
devicesto
themultifunctiondisplayviaRayNet
cables.Alsorequiredforconnectinga
crossovercouplerifonlyonedevice
isbeingconnectedtothedisplay's
Networkconnector.
PoweroverEthernet(PoE)
ThisproductcansupplyPoweroverEthernet(PoE)
toclass1,2and3devices.Theproductcanoutput
amaximumof20WattsforconsumptionbyPoE
devices.
ThePoEclassdenotesthepowerrangeofthePoE
device.
PoEClassPowerrangeClassdescription
Class1
0.44Wto3.84WVerylowpower
Class2
3.84Wto6.49WLowpower
Class3
6.49Wto12.95WMidpower
Class0
0.44Wto12.95W
-
Note:Theproductwillnotprovidepowertoclass
4devices.
52
