4.12IPCameraconnections
YoucanconnectIPcamerastoyourmultifunction
display.
Note:CompatibleIPcamerasmustbeabletobe
conguredto:
•automaticallyassignanIPaddressviaDHCP
priortoconnectingtoyourmultifunctiondisplay
ornetwork.
•allowunauthenticated,anonymousONVIF
access.
Pleaserefertotheinstructionssuppliedwithyour
IPcameraforcongurationdetails.
Note:Yourmultifunctiondisplaymustbepowered
upbeforepowerisappliedtoanynetworked
IPcameras,thisistoenableyourmultifunction
displaytoassigntheIPcamera(s)avalidIP
address.
IPcamera(s)canbeconnecteddirectlytoanetwork
connectoronyourmultifunctiondisplay.
D12900-2
3
2
1
4
ItemDescription
1
Multifunctiondisplayrearconnectorpanel
2
CAM200IP
3
RayNettoRJ45adaptorcable(A62360/A80151
/A80159)
4
Ethernetcoupler(R32142)
Note:
ThegSSeriesmultifunctiondisplayscanprovide
PoweroverEthernet(PoE)tocompatibleIP
cameras.
RefertothePoweroverEthernet(PoE)sectionfor
detailsonPoEassignment.
YoucanalsoconnectmultipleIPcamerasviathe
SeaTalk
hs
network
D12901-2
1
2
4
4 4
4
5
5
5
5
3
ItemDescription
1
Multifunctiondisplay
2Networkswitch
3
RayNettoRJ45adaptorcables(A62360/
A80151/A80159)
4
CAM200IPs
5
Ethernetcouplers(R32142)
Note:NetworkswitchesdonotprovidePoE,
connectedcamerasmusthavetheirownpower
supply.
TipIfyourIPcamera(s)arenotdetectedbyyour
multifunctiondisplay,trypowercyclingtheIP
camera(s)whilstleavingyourmultifunctiondisplay
poweredup.
IPcameraguidance
Raymarine
®
MFDsarecapableofdisplayingIP
camerafeeds.Whilstthird-partyIPcamerasmay
work,Raymarine
®
highlyrecommendsonlyusing
Raymarine
®
IPcamerassuchastheCAM200IP.
Asguidanceanythird-partyIPcameramustconform
tothefollowing:
•ThecameramustsupportH.264compressionand
RTSP(RealtimeStreamingProtocol).
•ThecameramustbeONVIFcompliant
•Thecameramustbecapableofandbesetupto
allowunauthenticatedanonymousaccess
•Thecameramustbecapableofandbesetupto
assignanIPaddressautomaticallyviaDHCP
•Thecameraresolutionmustbesettonohigher
than720p
Thecamerasettingsmustbecheckedandif
necessaryadjustedusingaPCandthesoftware
suppliedwiththecamera,priortoaddingthecamera
totheSeaTalk
hs
network.
Important:Raymarine
®
doesnotguarantee
compatibilitywiththird-partyIPcameras.
