Raymarine gS Series User Manual

Note:Themaximumlengthfortheradarpower
anddatadigitalcable(includinganyextensions)
is25m(82ft).
4.10Sonarmoduleconnection
Asonarconnectionisrequiredforshnder
applications.
Themultifunctiondisplaycanbeusedwiththe
followingsonarmodules:
•CP450C
•CP300
•CP100
Note:Youmustensurethatthecableends
connectedintothedisplayandsonarmodulehave
alocking/weather-tightmechanism.
Directsonarmoduleconnection
Onsmallersystems(withonly3networkdevices)
thesonarmodulemaybeconnecteddirectlytothe
display.
21
SeaTalk
hs
/ RayNet
4
3
D12896-1
1.Multifunctiondisplayrearconnectorpanel.
2.Sonarmodule.
3.Sonartransducercable.
4.Sonartransducer.
Sonarmoduleconnectionusinganetworkswitch
1
32
SeaTalk
hs
/ RayNet
SeaTalk
hs
/
RayNet
5
4
D12897-1
1.Multifunctiondisplayrearconnectorpanel.
2.Networkswitch.
3.Sonarmodule.
4.Sonartransducercable.
5.Sonartransducer.
Cablesandconnections57
