4.27Remotecontrolfunctions

ange

Buttons

Pair

Select

D12051-2

Arrow buttons

Shortcut button

ButtonApplicationwherefunctionavailable:

Defaultfunctions:Chart

Radar

Fishnder

WeatherHome-

screen

Range/zoom.•PressUPorDOWN

arrowformomentary

response.

•HoldUPorDOWN

arrowforcontinuous

response.

Openhomescreen.Shortcut:Hold

Selectapplication

inhomescreen

(inleft-to-right,

top-to-bottomorder).

•PressUPorDOWN

arrowformomentary

response.

•HoldUPorDOWN

arrowforcontinuous

response.

Togglemenuitemsand

optionsindialogsand

prompts(inleft-to-right,

top-to-bottomorder).

•PressUPorDOWN

arrowformomentary

response.

•HoldUPorDOWN

arrowforcontinuous

response.

Placewaypointat

vesselposition.

Shortcut

Mediaplayercontrol

(requiresaBluetooth

mediaplayerpaired

tothemultifunction

display).

•PressUP/DOWN

arrowfornext/

previoustrack.

•PressSHORTCUT

buttonforplay/

pause.

gSSeries
