3.UsetheRangeinorRangeoutcontrolsto
switchtheactiveapplicationbetweensplitscreen
andfullscreenviews.
Switchingtheactivepaneordisplayusing
thekeypad
TheSwitchActivebuttonisusedtoswitchtheactive
paneonamultiapplicationpageand/ortoswitch
theactivedisplay.
Withmultipledisplaysconnectedand/oramultiple
applicationpagedisplayed:
Cyclesequence
1.PresstheSwitchActivebuttontoenterswitch
mode.
2.UsetheRotaryControltocyclethroughthe
availablepanesand/ordisplays.
Thekeypadwillcyclethroughdisplaysinthe
orderinwhichtheywerepaired.Onmulti
applicationpagestheRangebuttonscanbeused
toswitchtheactiveapplicationbetweenfulland
splitscreen.
3.PresstheBackbuttonortheSwitchActive
buttontoexitswitchmode.
6.7Screenoverview
ScreenitemDescription
1Home—selecttheHomeicontoaccessthe
homescreen.
2
Databar—providesinformationaboutyour
vesselanditsenvironment.Theposition
andtypeofinformationinthedatabarcan
becustomizedfromtheHomescreen>
Customize>DatabarSet-upmenu,if
required.
3
Menu—themenuoptionsarespecictothe
applicationthatyouarecurrentlyusing.
4Pop-upmenu—menuoptionsaredisplayed
whentheMenuisselected.
5
Pop-upmessages—alertyoutoasituation
(suchasanalarm),orunavailablefunction.
Pop-upmessagesmayrequirearesponse
fromyou—forexample,selectOKtosilence
alarms.
6Dialogs—enabledatatobeselected,edited
orentered.Useinmanycommonfunctions
—forexample,editingawaypoint.
7
Contextmenu—providesinformationand
optionsspecictoeachapplication.
8
Statusbar—providesinformationspecic
toeachapplication.Thisinformationcannot
beeditedormoved.
Menus
Menusenableyouconguresettingsand
preferences.
Menusareusedinthe:
•Homescreen—tocongureyourmultifunction
displayandexternally-connectedequipment.
•Applications—tocongurethesettingsforthat
particularapplication.
