Raymarine gS Series User Manual

22.2Changingthecamerafeed
Changingthecamera/videofeed
OnaNewaSeriesorNeweSeriesdisplay,ifmore
than1feedisavailableyoucanchangewhichfeed
isdisplayedonthescreenusingtouch.
D12598-1
FromtheCameraapplication.
1.T ouchandswipeyourngeruptomovetothe
nextvideofeed.
2.T ouchandswipeyourngerdowntodisplaythe
previousvideofeed.
Changingthecamera/videofeed
OnaNewcSeriesorNeweSeriesdisplay,ifmore
than1feedisavailableyoucanchangewhichfeed
isdisplayedonthescreenusingtheJoystick.
FromtheCameraapplication
1.MovetheJoystickDowntodisplaythenext
videofeed.
2.MovetheJoystickUptodisplaytheprevious
videofeed.
Changingthecamera/videofeedusingthe
menu
Whenmorethan1feedisavailable,youcanchange
whichfeedisdisplayedonscreenusingthemenu.
FromtheCameraapplication:
1.SelectMenu.
2.SelectCameraView.
3.SelectCamera:.
4.Selectthefeedyouwanttodisplay.
22.3Displayingmultiplecamerafeeds
usingQuadView
WhenanIPcameraisavailableonthenetwork,the
CameraapplicationcanbesettoQuadView.In
QuadViewupto4camerafeedscanbeviewed
simultaneously.
QuadViewcanconsistofupto4xIPfeedsor1x
analogfeedandupto3xIPfeeds.
ToenableQuadView,fromtheCameraapplication:
1.SelectMenu.
2.SelectCameraView.
3.SelectLayout:sothatQuadViewisdisplayed.
4.Arrangethefeedsbyselectingafeedineach
oftheTop-Left,Top-Right,Bottom-Land
Bottom-Rmenuoptionsasrequired.
Analogfeedscanonlybedisplayedinthetop
leftcorner.
5.Thetopleftcornercanalsobesettocycle
throughallavailableanalogandIPfeedsusing
thecyclingoptionsavailableintheTop-Left
menu.
See22.4Cameracyclingfordetailsofcycling
feeds.
Recording,takingphotos,namingfeedsand
adjustingthevideoimagearenotsupportedinQuad
View;howeveritispossibletoswitchtoQuadView
whilstrecordinginSingleView.
Note:ExceptforgSSeriesdisplays,QuadView
isnotavailableonMFDswitha9inchorbelow
screensizewhentheCameraapplicationisbeing
viewedaspartofasplitscreenpage.
Note:DisplayingmultipleIPfeedsonmultiple
MFDssimultaneouslymaycausesomefeedsto
notbedisplayed.
Usingonscreencontrols
Ontouchscreendisplays,onscreencontrolsare
availabletoquicklyswitchbetweenQuadViewand
SingleView.
InQuadView:
1.Selectthefeed.
TheExpandicon
isdisplayed.
2.SelecttheExpandicontoviewthefeedin
fullscreen.
Cameraapplication
333
