PG-FP5 CHAPTER 4 PROGRAMMING GUI USAGE
R20UT0008EJ0400 Rev. 4.00 Page 74 of 240
Jul 15, 2010
Figure 4-44. Action Log Window After [Autoprocedure(E.P.)] Command Execution
>ep
Blank check Chip:
PASS, Erase skipped.
Program Chip:
10%
20%
30%
40%
50%
60%
70%
80%
90%
100%
PASS
Erase, Program operation finished.
>
(9) [Set O
ption bytes] command
The [Set O
ption bytes] command specifies the settings for the target device's option byte. When this command is
executed, the settings specified in the [Option byte setting] area on the [Advanced] tab of the Device Setup dialog
box are applied to the target device. For details of the option byte settings, see 4.3.3 (14) (c) <9> [Option byte
setting] area.
(10) [Set OCD
Security ID] command
The [Set OCD
Security ID] command specifies the settings for the target device's option byte. When this command
is executed, the settings specified in the [OCD ID setting] area on the [Advanced] tab of the Device Setup dialog
box are applied to the target device. For details of the OCD security ID settings, see 4.3.3 (14) (c) <8> [OCD ID
setting] area.
(11) [C
onnect] command
Executes the con command or dcon command. When the con command is executed a check will be added and
when the dcon command is executed the check will be removed. When “autocon off” or “autocon on” is executed
with the autocon command, the [connect] command is enabled or disabled. Refer to CHAPTER 8 USAGE
COMMUNICATION COMMANDS for details about the functions.
(12) [Sig
nature read] command
The [Sig
nature read] command reads target device product information, such as the device name and flash
memory information.
The read result is displayed in the action log window.
