PG-FP5 APPENDIX A MESSAGES
R20UT0008EJ0400 Rev. 4.00 Page 212 of 240
Jul 15, 2010
A.4 Error Messages Displayed in FP5 Message Display
(1/3)
No. Message Error Condition Possible Workaround
001 Invalid PRM data Invalid PRM data
The parameter file may include invalid data, or the file may be
defective. Re-set the file using the parameter file downloaded
from http://www2.renesas.com/micro/en/ods/
002 Not connected No device connected to FP5
Issue a ‘con’ command before the command causing this
error.
005 Not supported!
−
The command issued is not supported on the device and thus
cannot be used.
006 Command aborted! Command aborted The [Read] command has been canceled.
008 Parameter Error! PR5 file Error The parameter file may be damaged.
011 Read. Sig failed Device signature reading failed Check if the correct device is selected.
012 Check connection Connection check The FP5 cannot establish connection to the target device.
The cause may be a wrong connection between the device
and the FP5, bad socket contacts or the oscillator not
operating.
013 Addr. Range err Address range error
The address given in the command exceeds the device’s
address range.
014 RDY detect. fail Device does not send RDY signal.
Wrong connection between device and FP5 or bad socket
contacts.
015 Freq. set failed
Setting the Oscillator frequency
failed.
Check if the oscillator frequency is allowed. If yes, contact
Renesas Electronics support desk.
016 Baudrt. set fail
Setting the communication baud
rate failed.
Unsupported baud rate specified. Please consult the device
manual.
020 Inv. Sig. ID Invalid signature ID Check if the correct device is selected.
021 Inv. Sig. Code Invalid signature code Check if the correct device is selected.
022 Inv. Sig. func. Invalid signature function Check if the correct device is selected.
023 Inv. Sig. addr. Invalid signature address Check if the correct device is selected.
024 Inv. device name Invalid device name Check if the correct device is selected.
025 Inv. Signature Invalid signature Check if the correct device is selected.
026 Inv Dev/Firm ver Invalid device firmware version Check if the correct device is selected.
027 Unkn. Signature Unknown Signature Check, if the correct PRM file is used.
030 Prewrite Timeout Prewrite timed out
A communication problem occurred between the FP5 and
target device. Try the operation again.
032 Prewrite failed Prewrite retry error The device may be damaged.
040 Erase Timeout Erase timed out
A communication problem occurred between the FP5 and
target device. Try the operation again.
041 Erase failure Erase failed The device may be damaged.
042 Ers time exceed Erase timed out The device may be damaged.
043 Ers Timeset err Erase time setting error
The PR5 file may contain invalid data. Contact Renesas
Electronics.
To Next Page
