RL78/F13, F14 CHAPTER 36 ELECTRICAL SPECIFICATIONS (GRADE Y)
R01UH0368EJ0210 Rev.2.10 1829
Dec 10, 2015
36.6.6 LVD Circuit Characteristics
(1) LVD detection voltage of interrupt mode or reset mode
(T
A = -40 to +150C, VPDR  EVDD0 = EVDD1 = VDD  5.5 V, VSS = EVSS0 = EVSS1 = 0 V)
Parameter Symbol Conditions MIN. TYP. MAX. Unit
Detection
voltage
Supply voltage level VLVD0 Power supply rise time 4.62 4.74 5.22 V
Power supply fall time 4.52 4.64 5.11 V
VLVD1 Power supply rise time 4.50 4.62 5.09 V
Power supply fall time 4.40 4.52 4.98 V
VLVD2 Power supply rise time 4.30 4.42 4.87 V
Power supply fall time 4.21 4.32 4.76 V
VLVD3 Power supply rise time 3.13 3.22 3.55 V
Power supply fall time 3.07 3.15 3.47 V
VLVD4 Power supply rise time 2.95 3.02 3.33 V
Power supply fall time 2.89 2.96 3.23 V
VLVD5 Power supply rise time 2.74 2.81 3.11 V
Power supply fall time 2.68
Note
2.75 3.00 V
Minimum pulse width tLW 300 µs
Detection delay time tLD 300 µs
Note The minimum value exceeds below the lower limit operation voltage (2.7 V), however, in reset mode, normal
operation (same behavior when VDD = 2.7 V) is possible until a reset is effected at the power supply falling time.
(2) LVD detection voltage of interrupt and reset mode
(T
A = -40 to +150C, VPDR  EVDD0 = EVDD1 = VDD  5.5 V, VSS = EVSS0 = EVSS1 = 0 V)
Parameter Symbol Conditions MIN. TYP. MAX. Unit
Interrupt and reset
mode
V
LVD5
VPOC2, VPOC1, VPOC0 = 0, 0, 1
Note 1
,
falling reset voltage: 2.75 V
2.68
Note
2
2.75 3.00 V
VLVD2 LVIS1, LVIS0 = 1, 0 Rising release reset voltage 4.30 4.42 4.87 V
Falling interrupt voltage 4.21 4.32 4.76 V
VLVD5
VPOC2, VPOC1, VPOC0 = 0, 1, 0
Note 1
,
falling reset voltage: 2.75 V
2.68
Note
2
2.75 3.00 V
VLVD1 LVIS1, LVIS0 = 0, 0 Rising release reset voltage 4.50 4.62 5.09 V
Falling interrupt voltage 4.40 4.52 4.98 V
VLVD5
VPOC2, VPOC1, VPOC0 = 0, 1, 1
Note 1
,
falling reset voltage: 2.75 V
2.68
Note
2
2.75 3.00 V
VLVD3 LVIS1, LVIS0 = 0, 1 Rising release reset voltage 3.13 3.22 3.55 V
Falling interrupt voltage 3.07 3.15 3.47 V
VLVD0 LVIS1, LVIS0 = 0, 0 Rising release reset voltage 4.62 4.74 5.22 V
Falling interrupt voltage 4.52 4.64 5.11 V
Notes 1. These values indicate setting values of option bytes.
2. The minimum value exceeds below the lower limit operation voltage (2.7 V), however, in reset mode, normal
operation (same behavior when VDD = 2.7 V) is possible until a reset is effected at the power supply falling
time.
