RL78/F13, F14 CHAPTER 34 ELECTRICAL SPECIFICATIONS (GRADE L)

R01UH0368EJ0210 Rev.2.10 1695

Dec 10, 2015

(TA = -40 to +105C, 2.7 V  EVDD0 = EVDD1 = VDD  5.5 V, VSS = EVSS0 = EVSS1 = 0 V) (3/3)

Items Symbol Conditions MIN. TYP. MAX. Unit

Supply

current

Notes 1,

SNOZ SNOOZE mode

A/D converter

operation

During mode transition 1.0 1.2 mA

During

conversion

Low-voltage mode

REFP = VDD = 5.0 V

2.1 2.5 mA

DTC operation 4.5 mA

Notes 1. Total current flowing into VDD and EVDD0, including the input leakage current flowing when the level of the

input pin is fixed to VDD, EVDD0, VSS, or EVSS0. However, not including the current flowing into the I/O buffer

and on-chip pull-up/pull-down resistors.

2. The values below the MAX. column include the STOP leakage current.
