Renesas RL78/F14 User Manual

RL78/F13, F14 CHAPTER 35 ELECTRICAL SPECIFICATIONS (GRADE K)
R01UH0368EJ0210 Rev.2.10 1776
Dec 10, 2015
35.6.2 Temperatures Sensor Characteristics
(TA = -40 to +125C, 2.7 V  EVDD0 = EVDD1 = VDD  5.5 V, VSS = EVSS0 = EVSS1 = 0 V)
Parameter Symbol Conditions MIN. TYP. MAX. Unit
Temperature sensor output
voltage
V
TMPS25 Setting ADS register = 80H, TA = +25C 1.1 V
Reference output voltage VCONST Setting ADS register = 81H 1.38 1.45 1.5 V
Temperature coefficient FVTMPS
Temperature sensor that depends on the
temperature
-3.3 mV/C
Operation stabilization wait
time
t
AMP 5
µs
35.6.3 D/A Converter Characteristics
(T
A = -40 to +125C, 2.7 V  EVDD0 = EVDD1 = VDD  5.5 V, VSS = EVSS0 = EVSS1 = 0 V)
Parameter Symbol Conditions MIN. TYP. MAX. Unit
Resolution RES 8 bit
Overall error AINL Rload = 4 M 2.7 V  VDD  5.5 V 2.5 LSB
Rload = 8 M 2.7 V  VDD  5.5 V 2.5 LSB
Settling time tSET Cload = 20 pF 2.7 V  VDD  5.5 V 3
µs

35.6.4 Comparator Characteristics
(T
A = -40 to +125C, 2.7 V  EVDD0 = EVDD1 = VDD  5.5 V, VSS = EVSS0 = EVSS1 = 0 V)
Parameter Symbol Conditions MIN. TYP. MAX. Unit
Input offset voltage VIOCMP 5 40 mV
Input voltage range VICMP 0 VDD V
Response time tCR, tCF Input amplitude 100 mV 70 200 ns
Stabilization wait time
during input channel
switching
Note 1
tWAIT Input amplitude 100 mV 300 ns
Operation stabilization wait
time
Note 2
t
CMP 3.3 V  VDD  5.5 V 1
µs
2.7 V  VDD < 3.3 V 3
µs
Notes 1. Period of time from when the comparator input channel is switched until the comparator is switched to output
2. Period of time from when the comparator operation is enabled (HCMPON bit in CMPCTL is set to 1) until the
comparator satisfies the DC/AC characteristics.
