Ricoh G104 User Manual

Service Mode Table
G160/G161 5-160 SM
Reading SP5-803
-XXX
Bit Description
0 1
Not used
Input Check 4
0-3 Not used - -
4 Polygon Motor Fan Locked Not locked
5
Color Drum Gear Position
Sensor
Activated
(Actuator inside
sensor)
Deactivated
6
Black Drum Gear Position
Sensor
Activated
(Actuator inside
sensor)
Deactivated
004
7 Interlock Switch 24V Opened Closed
Input Check 5
005
Not used
Input Check 6
006
Not used
Input Check 11
0 Paper Size Sensor 1 Pushed Not Pushed
1 Paper Size Sensor 2 Pushed Not Pushed
2 Paper Size Sensor 3 Pushed Not Pushed
3 Paper Size Sensor 4 Pushed Not Pushed
4 Paper Width Sensor Pushed Not Pushed
5 Paper Height Sensor 1 Pushed Not Pushed
6 Paper Height Sensor 2 Pushed Not Pushed
011
7 Paper End Sensor Not End End
Input Check 12
0 Transfer Belt Contact Sensor Not Contact Contact
1 Transfer Roller Contact Sensor Not Contact Contact
2 Duplex Jam Sensor 1 Paper detected Paper not detected
3 Duplex Jam Sensor 1 Paper detected Paper not detected
4 Fusing New Unit Sensor New Old
5 Fusing Unit Set Sensor P1 Set Not Set
012
6 Fusing Unit Set Sensor P2 Set Not Set
