Service Mode Table
SM 5-161 G160/G161
G160/G161
Reading SP5-803
-XXX
Bit Description
0 1
7 Not Used - -
Input Check 13
0 Paper Overflow Sensor Overflow Not overflow
1 Fusing Exit Sensor Paper detected Paper not detected
2 Inverter Sensor Paper detected Paper not detected
3 Fusing Unit Fan Locked Not locked
4 PSU Fan Locked Not locked
5 Drive Unit Fan Locked Not locked
6 Paper Exit Fan Locked Not locked
013
7 Not used
Input Check 14
0 Toner End Sensor [Y] End Not end
1 Toner End Sensor [C] End Not end
2 Toner End Sensor [M] End Not end
3 Toner End Sensor [K] End Not end
4 New PCU Detection [Y] New Old
5 New PCU Detection [C] New Old
6 New PCU Detection [M] New Old
014
7 New PCU Detection [K] New Old
Input Check 15
0 LDU Shutter Sensor Close Open
1 Left Cover Sensor Close Open
2 Waste Toner Overflow Sensor Not overflow Overflow
3 By-pass Paper Detection Sensor Paper detected Paper not detected
4 By-pass Paper Size Sensor 1 Not used
5 By-pass Paper Size Sensor 2 Not used
6 By-pass Paper Size Sensor 3 Not used
015
7 By-pass Paper Size Sensor 4 Not used
Input Check 16
0-2 Not used - -
3 Fusing Entrance Sensor Paper detected Paper not detected
016
4 Transfer Belt New Unit Detection New Old
