RIGOL Chapter 6 Operations and Measurements
6-32 DS4000E User’s Guide
To Turn the Statistic Function On/Off
The oscilloscope provides the statistic function of the measurement results of
one-key measurement. You can make statistics of at most 5 measurement items that
are enabled lastly and display the statistic results.
Press Measure and press Statistic to turn the statistic function on or off.
When the statistic function is turned on, the specified items in the statistic results are
displayed at the bottom of the screen. Press Mode to select “Extremum” or
“Difference” statistic mode.
 Extremum: display the current value, average value, minimum value and
maximum value.
 Difference: display the current value, average value, standard deviation and
count value.
Besides, you can press Reset to clear the history data and make statistic again.
