RIGOL Chapter 12 Store and Recall
12-14 DS4000E User’s Guide
4. Input the other chracters
Use the same method to input the remaining Chinese characters “件名” by
referring to step 3.
5. Modify or delete the chracters input
When inputting the name, you can modify or delete the filename characters
input in the “Name Input Area” as well as delete the pinyin characters input in
the “Pinyin Input Area”.
1) Modify or delete the filename characters input in the “Name Input Area”
Press Name to select the “Name Input Area” and turn the multi-function
knob
to select the character to be modified or deleted; input the
desired character by referring to step 3 or press Delete to delete the
character.
2) Delete the pinyin characters input in the “Pinyin Input Area”
Press Keyboard to select the “Keyboard” area and press Delete
continuously to delete the pinyin characters input in the “Pinyin Input Area”
in order.
6. After finishing the input, press OK and the oscilloscope will create a folder or a
specified type of file with this name under the current directory.
To Delete a File or Folder
Folder operation is valid only in external storage mode. Before performing the
operation, make sure that a USB storage device is connected correctly.
1． Delete a file in the internal memory
1) Press Storage  Disk.Manage; turn the multi-function knob to select
the local disk (“local Disk”) and press the knob to open the local disk.
2) Press File Type and turn the multi-function knob to select the desired
type of file (include *.*, *.stp, *.pf and *.ref).
Note: Only *.stp, *.ref and *.pf types of files can be stored in the internal
memory. When other file type is selected, the disk information is empty.
3) Turn the multi-function knob
to select the file to delete.
4) Press Delete  OK to delete the file selected.
