RIGOL Chapter 11 Display Control
11-4 DS4000E User’s Guide
To Set the Waveform Brightness
Press Display  WaveIntensity and turn the multi-function knob to adjust
the display brightness of the waveform . The range available is from 0% to 100%.
The default is 50%.
In addition, when the operation menu at the right side of the screen are hidden, you
can turn the multi-function knob
to adjust the waveform brightness of the
channels. The current waveform brightness information is displayed at the
lower-right side of the screen.
To Specify the Screen Grid Type
Press Display  Grid and turn the multi-function knob to select the desired
grid type and press the knob. You can also press Grid continuously to switch the
current grid type.
 : turn the background grid and coordinate on.

: turn the background grid off and turn the coordinate on.

: turn the background grid and coordinate off.
To Set the Grid Brightness
Press Display  Brightness and turn the multi-function knob to adjust the
display brightness of the grid. The range available is from 0% to 100%. The default
is 50%.

Rigol DS4024E Specifications

General

Bandwidth	200 MHz
Channels	4
Vertical Sensitivity	1 mV/div to 10 V/div
Vertical Resolution	8 bits
Max Input Voltage	400 V (DC + AC peak)
Display	8 inch TFT LCD (800 x 480 pixels)
Input Impedance	1 MΩ
Trigger Modes	Edge, Pulse, Video
Timebase Range	2 ns/div to 50 s/div
Interfaces	USB, LAN
Input Coupling	AC, DC, GND
Power Supply	100-240 VAC, 45-440 Hz
Sample Rate	2 GSa/s (Real-time)
