RIGOL Chapter 13 System Function Setting
13-14 DS4000E User’s Guide
Note: This softkey is only available after the print is paused.
12. View the print status
Press Status to open the PictBridge status information interface. You can view
the current print statuses of the printer.
Power Status
The oscilloscope is powered on after you connect the oscilloscope to the AC source
using the power cord and turn on the power switch at the rear panel. You can set the
power status of the oscilloscope after power-on.
Press Utility and press PowerStatus to select “Default” or “Open”.
 Default: after the oscilloscope is powered on, you need to press the power key
at the front panel to start up the oscilloscope.
 Open: after the oscilloscope is powered on, it starts up directly.
Note: At this point, you can also press the power key at the front panel to turn
off or on the oscilloscope.
External Trigger Impedance
Users can set the external trigger impedance (namely the input impedance of the
[EXT TRIG] connector at the front panel) according to the actual situation.
Press Utility and press Extimpedance to select “1 MΩ” (default) or “50 Ω”.
Note: Please select the impedance that matches the input signal actually input from
the [EXT TRIG] connector at the front panel.
