Chapter 10 Waveform Recording RIGOL
DS4000E User’s Guide 10-1
Chapter 10 Waveform Recording
The waveform recording function provides various recording modes (Record 
Mode).
Record: record the channel waveforms at the specified interval until users stop the
recording operation manually or when the number of frames recorded reaches the
end frame currently set.
Open: record the channel waveform in real-time until users press RUN/STOP.
Playback: play back the waveform currently recorded.
Analyze: analyze the waveform currently recorded and provide the analysis results.
Note: The waveform recording function is only available when the horizontal time
base mode is “Y-T”.
The contents of this chapter:
 To Record Waveform Using the “Record” Mode
 To Record Waveform Using the “Open” Mode
 To Play Back the Waveform Recorded
 To Analyze the Recorded Waveform
