RIGOL Chapter 12 Store and Recall
12-6 DS4000E User’s Guide
To Perform Internal Storage and Recall
The internal memory supports the storage and recall of setup files, reference
waveform files and pass/fail test mask files. In the following section, the internal
storage and recall method and procedures are introduced by taking the setup file as
an example.
1. Save the specified oscilloscope setting in internal memory
1) Connect the signal to the oscilloscope and set the oscilloscope parameters to
obtain stable display.
2) Press Storage Storage; turn the multi-function knob to select
“Setups” and press the knob. You can also press Storage continuously to
switch to “Setups”.
3) Press Save to turn on the disk management interface. Turn the
multi-function knob
to select “Local Disk” (the characters turn green)
and press down the knob to open the local disk storage interface.
4) The local disk can store at most 10 setup files. Turn the multi-function knob
to select the desired storage location and Save becomes available; then
press the softkey to execute the saving operation. If the current location
contains a file, you can press Save OK to directly overwrite the original
file or press Delete to delete the file.
Note:
Turn the multi-function knob
to select and then press down
the knob to return to the previous directory.
In internal storage, New File and New Folder are not available.
Tip
1. Pressing REF Export can enter the disk management interface of
reference waveform file storage.
2. Pressing Utility Pass/Fail Save can enter the disk management
interface of pass/fail test mask file storage.
2. Recall the setup file stored in internal memory
1) Press Storage Storage; turn the multi-function knob to select
“Setups” and press the knob. You can also press Storage continuously to
switch to “Setups”.
2) Press Load to open the disk management interface. Turn the multi-function
To Next Page
