Chapter 8 Reference Waveform RIGOL
DS4000E User’s Guide 8-3
To Select the Current Reference Waveform Channel
Press REF  Current and turn the multi-function knob to select the desired
reference waveform channel (Ref1 to Ref10). You can also press Current
continuously to switch the current reference waveform channel.
Note:
 Only reference waveform channels that are turned on currently can be selected
as the current reference waveform channel (Current).
 The “To Set the Reference Waveform Color”, “To Select the Reference
Waveform Source Channel”, “To Save and Display the Reference
Waveform”, “To Adjust the Reference Waveform Display”, “To Export
the Reference Waveform File” and “To Import from the Reference
Waveform File” operations will all be applied to the current reference
waveform channel. Before making corresponding settings, select the reference
waveform channel to be set as the current reference waveform channel.
To Set the Reference Waveform Color
DS4000E series oscilloscope provides five colors (gray, green, light blue, magenta
and orange) to mark the reference waveforms of different channels in order to
distinguish them.
1. Press REF  Current to select the specified reference waveform channel (Ref1
to Ref10) as the current reference waveform channel.
2. Press Color; turn the multi-function knob to select a color for the current
reference waveform channel and press the knob. You can also press Color
continuously to switch the color currently selected.
Note: When the reference waveform color is modified, the color of the channel icon
at the left side of the screen grid will change accordingly.
