Chapter 8 Reference Waveform RIGOL
DS4000E User’s Guide 8-5
To Adjust the Reference Waveform Display
1. Display the reference waveform on the screen by referring to “To Save and
Display the Reference Waveform”.
2. Press and turn the multi-function knob to adjust the vertical position of
the reference waveform.
3. Press
and turn the multi-function knob to adjust the vertical scale of
the reference waveform.
Note: Pressing Reset will immediately restore the vertical position and vertical scale
of the reference waveform to the source channel settings when the “Save” operation
was executed.
To Export the Reference Waveform File
Users can save the current reference waveform to the internal memory or external
USB storage device (only when a USB storage device is detected) in “*.ref” format.
At most 10 reference waveform files (LocalREF0.ref to LocalREF9.ref) can be saved
in the internal memory.
1. Display the reference waveform on the screen and adjust the vertical position
and vertical scale of the reference waveform by referring to “To Save and
Display the Reference Waveform” and “To Adjust the Reference
Waveform Display”.
2. Press Export to enter the file store interface. Please refer to the relative
descriptions in “
Store and Recall” to save the reference waveform to internal
or external memory.
