Page #6 background image
RIGOL
IV DS4000E User’s Guide
Safety Terms and Symbols
Safety Notices in this Manual:
WARNING
Indicates a potentially hazardous situation or practice which, if not
avoided, will result in serious injury or death.
CAUTION
Indicates a potentially hazardous situation or practice which, if not
avoided, could result in damage to the product or loss of important data.
Safety Terms on the Product:
DANGER
It calls attention to an operation, if not correctly performed, could
result in injury or hazard immediately.
WARNING
It calls attention to an operation, if not correctly performed, could
result in
potential injury or hazard.
CAUTION
It calls attention to an operation, if not correctly performed, could
result in damage to the product or other devices connected to the
product.
Safety Symbols on the Product:
Hazardous
Voltage
Safety
Warning
Protective
Earth
Terminal
Chassis
Ground
Test
Ground

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Rigol DS4024E and is the answer not in the manual?

Rigol DS4024E Specifications

General IconGeneral
Bandwidth200 MHz
Channels4
Vertical Sensitivity1 mV/div to 10 V/div
Vertical Resolution8 bits
Max Input Voltage400 V (DC + AC peak)
Display8 inch TFT LCD (800 x 480 pixels)
Input Impedance1 MΩ
Trigger ModesEdge, Pulse, Video
Timebase Range2 ns/div to 50 s/div
InterfacesUSB, LAN
Input CouplingAC, DC, GND
Power Supply100-240 VAC, 45-440 Hz
Sample Rate2 GSa/s (Real-time)
