RIGOL Chapter 14 Remote Control
14-6 DS4000E User’s Guide
Remote Control via LAN
1. Connect the device
Connect the oscilloscope to your LAN using a network cable.
2. Configure the network parameters
Configure the network parameters of the oscilloscope according to “To
Configure the LAN Interface”.
3. Search for device resources
Start up Ultra Sigma and click
. The window as shown in figure (a) is
displayed. Click
in the window and the software will search for the
instrument resources currently connected to the LAN; the resources found are
displayed at the right of the window (as shown in Figure (b)). Click
to add the resource.
(a)
(b)
Note: If you want to remove the unwanted resource, click the resource name to
select it and then click
.
To Next Page
