Rockwell Automation Allen-Bradley PowerFlex 755T Installation Instructions

104 Rockwell Automation Publication 750-IN118A-EN-P - May 2021
Chapter 4 Power Wiring
Drive Fuses
Input
Rating
Applied
Rating
Cont.
Output
Amps
Duty
Input
Amps
Manufacturer
Manufacturer
Part Number
Specification
480V
600 Hp
765 Light 704
Cooper
Bussmann
170M6466 CLASS aR -690V, 1250 A
710 Normal 653 170M6466 CLASS aR -690V, 1250 A
545 Heavy 501 170M6466 CLASS aR -690V, 1250 A
650 Hp
800 Light 736 170M6466 CLASS aR -690V, 1250 A
740 Normal 681 170M6466 CLASS aR -690V, 1250 A
617 Heavy 568 170M6466 CLASS aR -690V, 1250 A
600V
250 Hp
295 Light 271 LPJ-400SP CLASS J -600V, 400 A
242 Normal 223 LPJ-350SP CLASS J -600V, 350 A
192 Heavy 177 LPJ-250SP CLASS J -600V, 250 A
300 Hp
355 Light 327 Mersen AJT500 CLASS J -600V, 600 A
295 Normal 271
Cooper
Bussmann
LPJ-400SP CLASS J -600V, 400 A
242 Heavy 223 LPJ-350SP CLASS J -600V, 350 A
350 Hp
395 Light 363 LPJ-600SP CLASS J -600V, 600 A
355 Normal 327 Mersen AJT500 CLASS J -600V, 500 A
295 Heavy 271
Cooper
Bussmann
LPJ-400SP CLASS J -600V, 400 A
400 Hp
435 Light 400 LPJ-600SP CLASS J -600V, 600 A
395 Normal 363
Mersen AJT500
CLASS J -600V, 500 A
355 Heavy 327 CLASS J -600V, 500 A
450 Hp
51 Light 469
Cooper
Bussmann
170M6463 CLASS aR -690V, 900 A
435 Normal 400 LPJ-600SP CLASS J -600V, 600 A
395 Heavy 363 Mersen AJT500 CLASS J -600V, 500 A
500 Hp
580 Light 534
Cooper
Bussmann
170M6463 CLASS aR -690V, 900 A
545 Normal 501 170M6463 CLASS aR -690V, 900 A
450 Heavy 141 LPJ-600SP CLASS J -600V, 600 A
690V
200 kW
265 Light 243 170M6461 CLASS aR -690V, 700 A
215 Normal 197 170M6461 CLASS aR -690V, 700 A
171 Heavy 157 170M6461 CLASS aR -690V, 700 A
250 kW
330 Light 303 170M6461 CLASS aR -690V, 700 A
265 Normal 243 170M6461 CLASS aR -690V, 700 A
215 Heavy 197 170M6461 CLASS aR -690V, 700 A
315 kW
370 Light 340 170M6461 CLASS aR -690V, 700 A
330 Normal 303 170M6461 CLASS aR -690V, 700 A
265 Heavy 243 170M6461 CLASS aR -690V, 700 A
355 kW
415 Light 381 170M6461 CLASS aR -690V, 700 A
370 Normal 340 170M6461 CLASS aR -690V, 700 A
330 Heavy 303 170M6461 CLASS aR -690V, 700 A
400 kW
460 Light 422 170M6463 CLASS aR -690V, 900 A
415 Normal 381 170M6461 CLASS aR -690V, 700 A
370 Heavy 340 170M6463 CLASS aR -690V, 900 A
500 kW
565 Light 519 170M6463 CLASS aR -690V, 900 A
505 Normal 464 170M6463 CLASS aR -690V, 900 A
415 Heavy 381 170M6463 CLASS aR -690V, 900 A
Table 16 - Frame 8 Configured Input Bay AC Line Input Protection Fuses (Continued)
