Rockwell Automation Allen-Bradley PowerFlex 755T Installation Instructions

16 Rockwell Automation Publication 750-IN118A-EN-P - May 2021
Chapter 1 Product Overview
Product Type and Voltage Rating
These options apply to the drive, common bus inverter, or bus supply.
Figure 9 - Product Type and Voltage Rating, Catalog Number Positions 1…7
A
Drive
Code
(1)
(1) For a stand-alone drive, common bus inverter, or bus supply, the code for the drive type is 20G or 20J. For a drive,
common bus inverter, or bus supply that is part of a PowerFlex 755T Drives Configured to Order Program product,
the code for the drive type is 24G or 24J.
Type Frames
24G
Configured PowerFlex 755TL Drives 8…9
Configured PowerFlex 755TR Drives 8…9
Configured PowerFlex 755TM Common Bus Inverters 8…9
24J Configured PowerFlex 755TM Bus Supplies 8…9
B
Corrosive Gas Protection and Cooling Type
Code Description Frames
E Corrosive Gas Protection (XT); Forced Air 8…9
C
Input Type
Code Description Frames
D Common Bus with DC Precharge 8…9
E Common Bus without DC Precharge 8…9
F
Regenerative and Low Harmonic Active Front End (AFE),
755TR Drives
8…9
Regenerative and Low Harmonic AFE, 755TM Bus
Supplies
8…9
G Low Harmonic AFE, 755TL Drives 8…9
D
Enclosure Type
Code Description Frames
3 IP21, UL Type 1; Floor Mount 8…9
4 IP54, UL Type 12; Floor Mount 8…9
E
Voltage Rating
Code Voltage Frames
C400V AC; 3 PH8…9
D 480V AC; 3 PH 8…9
E 600V AC; 3 PH 8…9
F 690V AC; 3 PH 8…9
1
45678 111213
_ _ _ __ _ _
23
_ _ _
9
10
_
_
_
A B C D E
