Rockwell Automation Allen-Bradley PowerFlex 755T Installation Instructions

Rockwell Automation Publication 750-IN118A-EN-P - May 2021 21
Chapter 1 Product Overview
Drive Input/Output Option Modules
Figure 14 - I/O Option Modules Added to the Drive, Catalog Number Positions 14…18
L
Port 4 I/O Option Module
Code Option Frames
N No Port 4 I/O Option module 8…9
A DeviceNet® 8…9
BSingle-port PROFINET8…9
C Dual-port PROFINET 8…9
D PF750 ControlNet 8
M
Port 5 I/O Option Module
Code Option Frames
N No Port 5 I/O Option module 8…9
AStandard Encoder8…9
B Dual Incremental Encoder 8…9
C Universal Feedback 8…9
N
Port 6 I/O Option Module
Code Option Frames
N No Port 6 I/O Option module 8…9
A Hardwired Safe Torque Off 8…9
B Hardwired Safe Speed Monitor 8…9
C Networked Safe Torque Off 8…9
D Integrated Safety Functions (Networked) 8
O
Port 7 I/O Option Module
Code Option Frames
N No Port 7 I/O Option Module 8…9
A 24V DC 2262C-2R (for internal controls) 8…9
B 115V AC 2262D-2R (for internal controls) 8…9
P
Port 8 I/O Option Module
Code Option (22-Series) Frames
N No Port 8 I/O Option Module 8…9
A 24V DC I/O, 2262C-2R wired to terminals 8…9
B 24V DC I/O, 2262C-2R card only 8…9
C 24V DC I/O, 2263C-1R2T wired to terminals 8…9
D 24V DC I/O, 2263C-1R2T card only 8…9
E 115V AC I/O, 2262D-2R wired to terminals 8…9
F 115V AC I/O, 2262D-2R card only 8…9
14
_
L
15
_
M
16
_
N
17
_
O
18
_
P
