Page #57 background image
Rockwell Automation Publication 750-IN118A-EN-P - May 2021 57
Chapter 3 Mechanical and Electrical Installation
Install Bay Joining
Hardware
For each configured bay that was shipped detached from the drive bays,
mechanically connect the configured bay to the drive bay. Use the joining
hardware that is shipped in a box with each configured bay. See Table 7
.
ATTENTION: Once two bays have been joined during installation, do not lift
them or move them in any way.
Table 7 - Standard Installation Joining Hardware
Frame Side 1 of Joining Side 2 of Joining Type of Joining Hardware
8
Section including
configured input bay and
drive bays
Configured output bay Top Brackets and Frame Clamps on page 58
9
Configured input bay with:
control-only
fuses with top or bottom
entry
circuit breaker with
bottom entry
Drive bays section Top Brackets and Frame Clamps on page 58
Configured input bay with
circuit breaker, top entry
Drive bays section
Internal Corner Brackets and Frame Clamps on
page 59
Drive bays section Configured output bay Top Brackets and Frame Clamps on page 58
