Rockwell Automation Allen-Bradley PowerFlex 755T Installation Instructions

24 Rockwell Automation Publication 750-IN118A-EN-P - May 2021
Chapter 1 Product Overview
Configured Output Bay
The options in this section apply to an optional configured output bay that is
connected to the drive. A dash precedes each code in this section.
Figure 17 - Configured Output Bay Options, Catalog Number Positions 32…35
AC
Load Cable Exit Location
Code Option Frames
N
No Configured Output Bay
(1)
(1) Sets all configured output bay options to 'N' to allow for options for a configured-input-
bay-only setup.
8…9
(2)
(2) For use with regenerative power supply products and TL/TR drives.
ATop Cable Exit8…9
B Bottom Cable Exit 8…9
AD
Output Power Filtering
Code Option Frames
N No Output Filter 8…9
A 3% Output Line Reactor 8…9
B 5% Output Line Reactor 8…9
CDV/DT Output
—
(1)
(1) Available in frame 8…9 via internal drive option
D
Sine-wave Output Filter
(2) (3)
(2) Sine-wave output filters are not CE rated. If your product includes a sine-wave filter, refer
to the product data nameplate for CE certification information.
(3) Sine-wave output filters are only required when motor cables are longer than 305 m
(1000 ft).
8…9
AE
Output Contactor
Code Option Frames
N No Output Contactor 8…9
A Output Contactor 8
AF
Input Protection Auxiliary Contacts - Added to IP Device
Code Option Frames
A 1 NC Aux Contact 8
B 1 NO Aux Contact 8
C 1 NO Aux Contact, 1 NC Aux Contact 8
D 1 NO Aux Contact, 2 NC Aux Contacts 8
E 2 NO Aux Contacts, 1 NC Aux Contact 8
F 2 NO Aux Contacts, 2 NC Aux Contacts 8
G 2 NO Aux Contacts, 3 NC Aux Contacts 8
H 3 NO Aux Contacts, 2 NC Aux Contacts 8
I 3 NO Aux Contacts, 3 NC Aux Contacts 8
J 4 NO Aux Contacts, 4 NC Aux Contacts 8
32
-_
AC
33
-_
AD
34
-_
AE
35
-_
AF
