Chapter 1 Product Overview
Product Normal Duty Rating
Catalog number positions 8…10 identify the normal duty rating of the drive,
common bus inverter, or bus supply. The set of normal duty rating codes is
different based on which PowerFlex 750-Series configured product the code is
for:
• PowerFlex 755T Drive Normal Duty Ratings, Catalog Number Positions
8…10 use codes in tables F1…F4.
• PowerFlex 755TM Bus Supply Normal Duty Ratings, Catalog Number
Positions 8…10 on page 18 use codes in tables G1…G4.
• PowerFlex 755T Common Bus Inverter Normal Duty Ratings, Catalog
Number Positions 8…10 on page 19 use codes in tables H1…H4.
Figure 10 - PowerFlex 755T Drive Normal Duty Ratings, Catalog Number Positions 8…10
1
45678 111213
_ _ _ __ _ _
23
_ _ _
9
10
_
_
_
F1…F4
F1 F2
PowerFlex 755T ND Drive Ratings PowerFlex 755T ND Drive Ratings
400V, 50 Hz Input 480V, 60 Hz Input
Code Amps kW Frame Code Amps Hp Frame
302 302 160
8
302 302 250
8
367 367 200 361 361 300
460 460 250 430 430 350
540 540 315 505 505 400
585 585 315 545 545 450
650 650 355 617 617 500
750 750 400 710 710 600
770 770 400 740 740 650
920 920 500
9
800 800 700
9
1K0 1040 560 960 960 800
1K1 1112 630 1K0 1045 900
1K2 1175 710 1K1 1135 1000
1K4 1463 800 1K3 1365 1100
F3 F4
PowerFlex 755T ND Drive Ratings PowerFlex 755T ND Drive Ratings
600V, 60 Hz Input 690V, 50 Hz Input
Code Amps Hp Frame Code Amps kW Frame
242 242 250
8
215 215 200
8
295 295 300 265 265 250
355 355 350 330 330 315
395 395 400 370 370 355
435 435 450 415 415 400
545 545 550 505 505 500
