Chapter 5 Frame 6 Renewal Kits Installation
Install the Upper Stirring Fan
Install the upper stirring fan in the reverse order of removal.
Lower Stirring Fan Assembly
Replacement
Replacement kits catalog numbers: SK-RT-STIRFANL1-F6,
SK-RT-STIRFANL1-F6-XT.
These kits can be used for all enclosure types.
Remove the Lower Stirring Fan Assembly
Follow these steps to remove the lower stirring fan assembly.
1. Review the Product Advisories
on page 11.
2. Turn off and lock-out incoming power. See Remove Power from the
System on page 12.
3. Access the drive interior:
• For IP00, NEMA/UL Open Type, IP21, NEMA/UL Type 1, and flange,
NEMA/UL Type 4X/12 back enclosures, remove the drive cover. See
Remove the Cover
on page 83.
• For IP54, NEMA/UL Type 12 enclosures, open the enclosure door and
remove the protective guard.
IMPORTANT Verify that the stirring fan harness is inserted into the two wire harness
clips on the chassis.
