Rockwell Automation Publication 750-TG101A-EN-P - June 2022 33
Chapter 4
Frames 1…5 Renewal Kits Installation
This chapter provides detailed instructions for how to remove and replace
PowerFlex® 755TS frames 1…5 product components with renewal kit
components.
Frames 1…5 Kits Table 3 contains the renewal kits available for PowerFlex 755TS frames 1…5
products. ‘XT’ in the kit catalog number identifies a kit that can contain
protective covers and/or dielectric grease on connectors. See Renewal Kits for
PowerFlex 755TS Products with Corrosive Gas Protection (XT) on page 16
for
details.
Table 3 - Frames 1…5 Renewal Kits
Kit Description
Catalog Number
Frame
Size
Instructions
Standard XT
Power Terminal Cover
(for IP20, NEMA/UL Open Type,
IP20, NEMA/UL Type 1, and
Flange, NEMA/UL Type 4X/12 Back
Enclosures)
SK-RT-CVR1-F1 SK-RT-CVR1-F1-XT 1
See page 39
SK-RT-CVR1-F2 SK-RT-CVR1-F2-XT 2
SK-RT-CVR1-F3 SK-RT-CVR1-F3-XT 3
SK-RT-CVR1-F4 SK-RT-CVR1-F4-XT 4
SK-RT-CVR1-F5 SK-RT-CVR1-F5-XT 5
IP54, NEMA/UL Type 12 Enclosure Cover
SK-RT-CVR12-F2 SK-RT-CVR12-F2-XT 2
See page 40
SK-RT-CVR12-F3 SK-RT-CVR12-F3-XT 3
SK-RT-CVR12-F4 SK-RT-CVR12-F4-XT 4
SK-RT-CVR12-F5 SK-RT-CVR12-F5-XT 5
Chassis
(for IP20, NEMA/UL Open Type,
IP20, NEMA/UL Type 1, and
Flange, NEMA/UL Type 4X/12 Back
Enclosures)
SK-RT-CHSS1-F1 SK-RT-CHSS1-F1-XT 1 See page 41
SK-RT-CHSS1-F2 SK-RT-CHSS1-F2-XT 2
See page 46
SK-RT-CHSS1-F3 SK-RT-CHSS1-F3-XT 3
SK-RT-CHSS1-F4 SK-RT-CHSS1-F4-XT 4
SK-RT-CHSS1-F5 SK-RT-CHSS1-F5-XT 5
Flange Gasket
(for Flange, NEMA/UL Type 4X/12 Back
Enclosures)
SK-RT-FG1-F2
—
2
See page 49
SK-RT-FG1-F3 3
SK-RT-FG1-F4 4
SK-RT-FG1-F5 5
Control Pod Printed Circuit Board Fan
(for All Enclosure Types)
SK-RT-PODFAN1 SK-RT-PODFAN1-XT
2
See page 54
3
4
5
Heatsink Fan
(for IP20, NEMA/UL Open Type and
IP20, NEMA/UL Type 1 Enclosures)
SK-RT-HSFAN1-F12 SK-RT-HSFAN1-F12-XT
1
See page 57
2
SK-RT-HSFAN1-F3A,
SK-RT-HSFAN1-F3
SK-RT-HSFAN1-F3A-XT,
SK-RT-HSFAN1-F3-XT
3
SK-RT-HSFAN1-F4 SK-RT-HSFAN1-F4-XT 4
See page 58
SK-RT-HSFAN1-F5A,
SK-RT-HSFAN1-F5
SK-RT-HSFAN1-F5A-XT,
SK-RT-HSFAN1-F5-XT
5
