Rockwell Automation Publication 750-TG101A-EN-P - June 2022 79
Chapter 4 Frames 1…5 Renewal Kits Installation
Install the Backplane Circuit Board, Frames 2…5
Install the backplane circuit board in the reverse order of removal.
• Do not remove the protective covers from the connectors on the new
backplane circuit boards unless a connection must be made during
installation.
IMPORTANT Do not remove protective covers unless used at the time of installation. For
the product to meet the corrosive atmosphere rating, protective covers
must remain installed in unused connectors during storage and operation.
See Protective Covers on Kits with XT
on page 16 for details.
