Rockwell Automation Publication 750-TG101A-EN-P - June 2022 21
Chapter 1 Before You Begin Tests, Maintenance, or Repairs
Commonly Used Tools This table includes the tools that are needed for test measurements, basic
maintenance, and service repairs.
Software Tools
Connected Components Workbench™ software is an application that can be
used to upload and download parameter configuration and monitor system
parameters. Connected Components Workbench version 15.01 or later is
required for use with PowerFlex 755TS products.
IMPORTANT Care must be taken to be sure that tools and/or hardware components do
not fall into open drive assemblies. Do not energize the drive unless all
loose tools and/or hardware components have been removed from the
drive assemblies and enclosure.
Service Tools
Tool Description Details
Allen (hex) socket wrench 4 mm
Box wrench 7 mm, 8 mm, 10 mm
Crimp tools For cable terminals 1.5...240
Current clamp 1000 A (AC, rms), signal output
ESD-protected place of work Work surface, floor cover, seat, and ground connections
ESD-protective clothing Wrist wrap, shoes, overall clothing (coat)
Flash light / Task light For inspections
Flat-nose screwdriver 3 mm (0.12 in.), 5 mm (0.19 in.), 6.4 mm (0.25 in.)
Hexagonal socket wrench 7 mm, 8 mm, 10 mm
Insulation tester 1000V DC
Lift strap 5/16 in. J-hook style, 24 in. long, 1000 lb. min
Multi-meter
Digital multi-meter, capable of AC and DC voltage, continuity, resistance, capacitance
measurements, and forward diode bias tests. Fluke model 87 III or equivalent.
Nose pliers –
Oscilloscope Portable, digitizing, dual channel scope, with isolation
Torque wrench 1...12 N
•m (8.8…106 lb•in)
Torx screw driver/bit #15, #20, #25, #30
Wire cutter –
