Chapter 5
Frame 6 Renewal Kits Installation
This chapter provides detailed instructions for how to remove and replace
PowerFlex® 755TS frame 6 product components with renewal kit components.
Frame 6 Kits Table 4 contains the renewal kits available for PowerFlex 755TS frame 6
products. ‘XT’ in the kit catalog number identifies a kit that can contain
protective covers and/or dielectric grease on connectors. See Renewal Kits for
PowerFlex 755TS Products with Corrosive Gas Protection (XT) on page 16
for
details.
Table 4 - Frame 6 Renewal Kits
Kit Description
Catalog Number
Instructions
Standard XT
Control Pod Access Cover
(for IP00, NEMA/UL Open Type,
IP21, NEMA/UL Type 1, and
Flange, NEMA/UL Type 4X/12 Back Enclosures)
SK-RT-AD1-F67 SK-RT-AD1-F67-XT See page 85
Cover
(for IP00, NEMA/UL Open Type,
IP21, NEMA/UL Type 1, and
Flange, NEMA/UL Type 4X/12 Back Enclosures)
SK-RT-CVR1-F6 SK-RT-CVR1-F6-XT See page 86
Control Pod Human Interface Module (HIM) Cradle
(for All Enclosure Types)
SK-RT-BZL1 SK-RT-BZL1-XT See page 86
Main Control Board SK-RT-MCB1-PF755 SK-RT-MCB1-PF755-XT See page 89
Main Control Board to Power Interface Board
Ribbon Cable
— SK-RT-PIC1-F27-XT See page 94
Backplane Circuit Board SK-RT-BKPLN SK-RT-BKPLN-XT See page 96
Heatsink Fan
(for IP00, NEMA/UL Open Type and
IP21, NEMA/UL Type 1 Enclosures)
SK-RT-HSFAN1-F6 SK-RT-HSFAN1-F6-XT See page 97
Heatsink Fan
(for Flange, NEMA/UL Type 4X/12 Back and
IP54, NEMA/UL Type 12 Enclosures)
— SK-RT-HSFAN2-F6-XT See page 97
Upper Stirring Fan
(for IP00, NEMA/UL Open Type,
IP21, NEMA/UL Type 1,
Flange, NEMA/UL Type 4X/12 Back, and
IP54, NEMA/UL Type 12 Enclosures)
SK-RT-STIRFAN1R-F6 SK-RT-STIRFAN1R-F6-XT See page 99
Lower Stirring Fan Assembly
(for IP00, NEMA/UL Open Type,
IP21, NEMA/UL Type 1,
Flange, NEMA/UL Type 4X/12 Back, and
IP54, NEMA/UL Type 12 Enclosures)
SK-RT-STIRFANL1-F6 SK-RT-STIRFANL1-F6-XT See page 100
Flange Gasket
(for Flange, NEMA/UL Type 4X/12 Back
Enclosures)
SK-RT-FG1-F6 — See page 102
