Rockwell Automation Publication 750-TG101A-EN-P - June 2022 131
Chapter 6 Frame 7 Renewal Kits Installation
Cover Replacement Replacement kit catalog numbers: SK-RT-CVR1-F7, SK-RT-CVR1-F7-XT
These kits can be used for IP00, NEMA/UL Open Type, IP21, NEMA/UL Type 1
and Flange, NEMA/UL Type 4X/12 back enclosures.
Remove the Cover
Follow these steps to remove the cover.
1. Review the Product Advisories
on page 11.
2. Turn off and lock-out incoming power. See Remove Power from the
System on page 12.
3. Remove the control pod access cover. See Remove the Control Pod Access
Cover on page 130. Retain the access cover for reuse.
4. Remove the drive cover. See Remove the Cover
on page 128.
Install the Cover
Install the cover in the reverse order of removal.
Control Pod HIM Cradle
Replacement
Replacement kit catalog numbers: SK-RT-BZL1, SK-RT-BZL1-XT
These kits can be used for all enclosure types.
Remove the Control Pod HIM Cradle
Follow these steps to remove the control pod HIM cradle.
1. Review the Product Advisories
on page 11.
2. Turn off and lock-out incoming power. See Remove Power from the
System on page 12.
3. Access the drive interior:
• For IP00, NEMA/UL Open Type, IP21, NEMA/UL Type 1, and flange,
NEMA/UL Type 4X/12 back enclosures, remove the drive cover. See
Remove the Cover
on page 128.
• For IP54, NEMA/UL Type 12 enclosures, open the enclosure door.
4. If a HIM is installed in the cradle, remove the HIM.
