Siemens SIMOTICS S-1FL6 User Manual

Basic operator panel (BOP)
6.5 Auxiliary functions
SINAMICS V90, SIMOTICS S-1FL6
Operating Instructions, 04/2019, A5E36037884-007
203
6.5.4
Transferring data (drive to SD)
You can save the parameter set from the drive ROM to a micro SD card/SD card with the
BOP. To do this, proceed as follows.
Note
Data tra
nsfer between the drive and the SD card is possible only when the drive is in "S
OFF" state.
Note
Plugging or unplugging the micro SD card/SD card will cause transferring failure.
Do not plug or unplug the micro SD card/SD card during transferring; oth
erwise, the
transferring operation will fail.
Note
Write protection function is not supported by SINAMICS V90. Data in the micro SD card/SD
card will be overwritten even if the write protection function of the micro SD card/SD card is
enabled.
6.5.5
Transferring data (SD to drive)
You can also upload the parameters from a micro SD card/SD card to the drive ROM. To do
this, proceed as follows.
Note
Data transfer between the drive and the SD card is possible only when the drive is in "S
OFF" state.
