Siemens SIMOTICS S-1FL6 User Manual

General information
2.5 Accessories
SINAMICS V90, SIMOTICS S-1FL6
50 Operating Instructions, 04/2019, A5E36037884-007
2.5.5
Fuse/Type-E combination motor controller
A fuse/Type-E combination motor controller can be used to protect the system. Integral solid
state short circuit protection does not provide branch circuit protection. Branch circuit
protection must be provided in accordance with the National Electrical Code and any
additional local codes. Refer to the table below for the selection of fuses and Type-E motor
controllers:
200 V variant
SINAMICS V90
Recommended fuse
Type-E combination motor controller
1)
Frame
size
Rated
power
(kW)
CE-compliant
UL/cUL-compliant
listed (JDDZ) fuse
Rated cur-
rent (A)
Rated volt-
age (VAC)
Rated
power
(hp)
Article num-
ber
3RV 2011-
1-phase, 200 VAC to 240 VAC
FSA
0.1
3NA3 801 (6 A)
6 A
2.8 to 4
230/240
1/3
1EA10
0.2 3NA3 801 (6 A) 6 A 2.8 to 4 230/240 1/3 1EA10
FSB
0.4
3NA3 803 (10 A)
10 A
5.5 to 8
230/240
1
1HA10
FSC
0.75
3NA3 805 (16 A)
20 A
9 to 12.5
230/240
2
1KA10
3-phase, 200 VAC to 240 VAC
FSA
0.1
3NA3 801 (6 A)
6 A
2.8 to 4
230/240
3/4
1EA10
0.2
3NA3 801 (6 A)
6 A
2.8 to 4
230/240
3/4
1EA10
FSB
0.4
3NA3 803 (10 A)
10 A
2.8 to 4
230/240
3/4
1EA10
FSC
0.75
3NA3 805 (16 A)
20 A
5.5 to 8
230/240
2
1HA10
FSD
1.0
3NA3 805 (16 A)
20 A
7 to 10
230/240
3
1JA10
1.5
3NA3 810 (25 A)
25 A
10 to 16
230/240
5
4AA10
2.0
3NA3 810 (25 A)
25 A
10 to 16
230/240
5
4AA10
1)
The above types for Type-E combination motor controllers are listed in compliance with both CE and UL/cUL standards.
400 V variant
SINAMICS V90
Recommended fuse type
Type-E combination motor controller
1)
Frame
size
Rated
power
(kW)
CE-compliant
UL/cUL-compliant
listed (JDDZ) fuse
Rated cur-
rent (A)
Rated volt-
age (VAC)
Rated
power
(hp)
Article num-
ber
3RV 2021-
3-phase, 380 VAC to 480 VAC
FSAA
0.4
3NA3 801 (6 A)
10 A
2.2 to 3.2
380/480
0.5
1DA10
FSA
0.75
3NA3 801 (6 A)
10 A
2.8 to 4
380/480
1
1EA10
1.0
3NA3 803 (10 A)
10 A
3.5 to 5
380/480
1.34
1FA10
FSB
1.5
3NA3 803 (10 A)
15 A
5.5 to 8
380/480
2
1HA10
2.0
3NA3 805 (16 A)
15 A
11 to 16
380/480
2.68
4AA10
FSC
3.5
3NA3 807 (20 A)
25 A
14 to 20
380/480
4.7
4BA10
5.0
3NA3 807 (20 A)
25 A
14 to 20
380/480
6.7
4BA10
7.0 3NA3 810 (25 A) 25 A 20 to 25 380/480 9.4 4DA10
1)
The above types for Type-E combination motor controllers are listed in compliance with both CE and UL/cUL standards.
