2.7 Technical data
SINAMICS V90, SIMOTICS S-1FL6
68 Operating Instructions, 04/2019, A5E36037884-007
2.7.2
Technical data - servo motors
2.7.2.1
1FL6 servo motor - low inertia
General technical data
Parameter
Description
Type of motor
Permanent-magnet synchronous motor
Cooling
Self-cooled
Relative humidity [RH]
90% (non-condensing at 30°C )
Installation altitude [m] ≤ 1000 (without power derating)
Thermal class
B
Vibration severity grade
A (according to IEC 60034-14)
Shock resistance [m/s
2
] 25 (continuous in axial direction); 50 (continuous in radial direction); 250
(in a short time of 6 ms)
Bearing lifetime [h]
> 20000
1)
Paint finish
Black
Protection degree of shaft
IP 65, with shaft oil seal
Type of construction
IM B5, IM V1, and IM V3
Positive rotation Clockwise (default setting in servo drives)
Certification
1)
This lifetime is only for reference. When a motor keeps running at rated speed under rated load, replace its bearing after
20,000 to 30,000 hours of service time. Even if the time is not reached, the bearing must be replaced when unusual
noise, vibration, or faults are found.
Specific technical data
Article No. 1FL60...
22
24
32
34
42
44
52
54
Rated power [kW]
0.05
0.1
0.2
0.4
0.75
1
1.5
2
Rated torque [Nm]
0.16
0.32
0.64
1.27
2.39
3.18
4.78
6.37
Maximum torque
[Nm]
0.48 0.96 1.91 3.82 7.2 9.54 14.3 19.1
Rated speed [rpm]
3000
Maximum speed
[rpm]
5000
Rated frequency [Hz]
200
Rated current [A]
1.2
1.2
1.4
2.6
4.7
6.3
10.6
11.6
Maximum current [A]
3.6
3.6
4.2
7.8
14.2
18.9
31.8
34.8
