Appendix
A.1 Cable assembly
SINAMICS V90, SIMOTICS S-1FL6
414 Operating Instructions, 04/2019, A5E36037884-007
NOTICE
Drive damage resulting from the short-circuiting between the shielding wire and the unused
pin on the setpoint connector
The shielding wire may inadvertently be short-circuited to the unused pin on the to-be-
assembled setpoint connector. This can cause damage to the drive.
• When assembling the connector, exercise caution when connecting the shielding cable
to the setpoint connector.
A.1.2
Assembly of cable connectors on the motor side
A.1.2.1
Power connector assembly
Power cable used for low inertia motors (SH20, SH30, SH40)
