General information
2.7 Technical data
SINAMICS V90, SIMOTICS S-1FL6
78 Operating Instructions, 04/2019, A5E36037884-007
2.7.3
Technical data - cables
Parameter
MOTION-CONNECT 300
Power Cable
MOTION-CONNECT 300
Encoder Cable
MOTION-CONNECT 300
Brake Cable
General technical data
Jacket material PVC PVC PVC
Number of cores
4
10
2
Operation temperature (°C) -25 to 80
Shielding Yes
• Coverage ≥ 60%:
For 200 V variant servo drives + low inertia motors of 0.05 kW to 1 kW
• Coverage ≥ 85%:
For 200 V variant servo drives + low inertia motors of 1.5 kW to 2 kW, and for 400 V
variant servo drives + high inertia motors of 0.4 kW to 7 kW
Minimum bending radius,
static (mm)
5 x outer diameter
Minimum bending radius,
dynamic (mm)
155
Oil resistance
EN60811-2-1 fulfilled
Flame-retardant
EN60332-1-1 to 1-3 fulfilled
Certification
RoHS, CE
RoHS
RoHS
Specific technical data
Cable used for 200 V variant servo drive + low inertia motor of 0.05 kW to 1 kW
Rated voltage (V)
220
24
24
Cross-section of cores (mm
2
)
4 x 0.75
3 x 2 x 0.20 + 2 x 2 x 0.25
2 x 0.75
Outer diameter (mm)
ø (6.7±0.4)
ø (7.2±0.3)
ø (6.1±0.3)
Degree of protection (motor-
side only)
IP20
Bending cycles 100000:
Maximum acceleration 3 m/s
2
, maximum speed 40 m/min
Cable used for 200 V variant servo drives + low inertia motors of 1.5 kW to 2 kW, and for 400 V variant servo drives + high
inertia motors of 0.4 kW to 7 kW
Cross-section of cores (mm
2
)
• 4 x 1.5:
For high inertia motors of
0.4 kW to 1 kW
• 4 x 2.5:
For low inertia motors of
1.5 kW to 2 kW and high
inertia motors of 1.5 kW
to 7 kW
3 x 2 x 0.22 + 2 x 2 x 0.25 2 x 0.75
Rated voltage (V)
380
24
24
